Micro-Pocket™ Drill Guide

Create More Compact Pocket Holes in the Same Kreg Joinery Applications
25% smaller pocket-hole diameter
Great for smaller projects, thinner stock, and repair applications
Compatible with the Kreg Jig® K3, K4, K4MS, and K5
Features black color to differentiate from standard Kreg Drill Guide
Works with 1/2" (12mm) stock and narrow stock, down to 1" (25mm) wide
Works with Kreg Pan-Head Pocket-Hole Screws (SPS)

ITEM#: KJMICRODGB

Out of Stock

Description

With a 25% smaller hole diameter, the Micro-Pocket™ Drill Guide lets you create compact, low-profile pocket holes in the same Kreg Joinery applications where you'd use standard Kreg pocket holes, and in a variety of other applications, too. You also have the ability to tackle smaller projects, thinner stock, and tighter repairs where standard pocket holes simply can’t go.
Choose Your Jig
Compatible with the Kreg Jig® K3, K4, K4MS, and K5. Features black color to differentiate from the standard Kreg Drill Guide.
Endless Applications
A 25% smaller pocket hole works great in virtually every application where you’d use standard Kreg pocket holes. And because it removes less material, drill strokes are faster and easier.
Perfect for 1/2" Stock
Screw heads seat well below the material surface in thin stock, making the Micro-Pocket™ Drill Guide perfect for creating fully-pluggable pocket holes in 1/2" (12mm) thick material like drawer boxes.
Perfect for Narrow Stock
Reduced width lets you drill two holes in extremely narrow stock, down to 1" wide, creating a much stronger joint in narrow pieces.

Specs

Compatible with

Kreg Jig® K3, K4, K4MS, and K5
Body Material

Glass-filled nylon
Number of Drill Guides

Three 19/64" (7mm) diameter standard Kreg pocket holes
Drill Guide Spacing

9/16", 7/8", 17/16"
14mm, 22m, 36mm
Screw-Centering Ability

1/2", 5/8", 3/4" , 7/8", 1", 11/8", 11/4", 13/8", 11/2"
12mm, 16mm, 19mm, 22mm, 25mm, 28mm, 31mm, 35mm, 38mm
Includes

Micro Drill Guide Block, Micro drill bit, stop collar, Allen wrench, sample Kreg Screws, and owner's manual.
